ATS System 9500W Single Phase

This automatic transfer switch allows on-off control of devices such as generators & is compatible with our 2021 Hyundai Diesel Silent Generator 9500W single phase (934770).

This automatic transfer switch allows on-off control of devices such as generators.

An ATS (automatic transfer switch) is used to change the power source to a secondary source, usually a generator, in case of power failure. When there is a failure of the primary power source the ATS automatically starts the generator and switches the input power to the generator. When the primary power source is restored the ATS resets the primary input.

SPECIFICATIONS
Voltage: 230V
Maximum power output: 10kW
Maximum current: 45A
Transfer delay time: 2-5 seconds
Return delay: 10 – 20 seconds
Connections: Generator monitor 5 pin connector
Dimensions: W 35cm x D 34.5cm x H 25cm
Weight: 4.35kg
Compatibility: Hyundai Diesel Silent Generator 9500W (934770)
